ID: 76438
Omschrijving
WiFi Basis Station with PIR Detection Sensor, Door/Window Contact & Remote Control
Features
- Modularly expandable, connect max. 32 detectors
- Connection with up to 6 remote controls
- Push message at alarm release & emergency call
- Two-way communication between detector & basis station
- Transmission distance from detectors to basis station ~200m open areas
- Adjustable alarm tone volume (mute, silent, loud)
- Easy installation & configuration via Smartphone with My Secure Pro APP (iOS & Android)
- Activate & deactivate of the alarm system via remote control or APP
- 5V/2A power supply via USB power adapter
Technical specifications - Embedded Micro Controller & Linux OS
- 128-Bit AES encryption algorithm
- Wireless connections up to 32 detectors (868MHz) up to 6 remote controls/transmission distance ~10m (open areas)
- Audio output built-in loudspeaker (alarm tone only)
- WiFi protocol IEEE 802.11b/g/n, distance ~25m
- Power supply (Micro USB) DC 5V/2A, max. 10W
- Working temperature &ndash10°C ~ +50°C
- Installation wall mounting (indoor only)
Package contents - 1 WiFi basis station with 1x USB power adapter, 1x Micro USB cable, 3x screws, 3x dowels, 1x adhesive tape
- 1 PIR detection sensor with 1x bracket (on the device), 4x screws, 4x dowels, 1x CR123A battery
- 1 Door and window contact with 4x screws, 4x dowels, 1x CR123A battery, 2x adhesive tape
- 1 Remote control with 1x CR2032 battery 3V (installed in device)
- CD
- User Manual
Weight and Dimensions - Weight device 96g
- Dimensions device (L) 9.4 x (W) 11.4 x (H) 1.8cm
Features & technical specifications PIR detection sensor TX-85 - Alarm release at motion detection with ~12m detection range
- Built-in vadalism alarm (case & wall)
- Two-way communication between PIR & basis station
- Transmission frequency/distance 868MHz/~200m open areas
- Detection method passiv infrared (not visible 6500 LUX illumination)
- Two levels of sensitivity adjustable
- Viewing angle 90° horizontal & 70° vertical
- Push message at low battery level
- Battery lifespan ~2.5&ndash3 years
- Wall/corner installation indoor only (H ~2,1&ndash2,5m)
- Weight / Dimensions 77g (without battery) / (L) 10.5 x (W) 6.2 x (H) 4.2cm
Also available as single device. EAN code 4260358122519, Article No. 4690
Features & technical specifications door & window contact TX-86 - Sensor alarm triggering at ~2.5cm distance
- Built-in vadalism alarm (case & wall)
- Two-way communication between contact & basis station
- Transmission frequency/distance 868MHz/~200m open areas
- Alarm prompt Red LED
- Push message at low battery level
- Battery lifespan ~2.5&ndash3 years
- Fix installation indoor only (screws or adhesive tape)
- Weight / Dimensions Sensor 33g (without battery) / (L) 8.3 x (W) 3.8 x (H) 2.0cm
- Weight / Dimensions Magnet 34g / (L) 8.3 x (W) 2.5 x (H) 2.0cm
Also available as single device. EAN code 4260358122526, Article No. 4691
Features & technical specifications remote control TX-87 - SOS button for emergency calls with Push message
- 4 adjustments possible activate, stay at home, disarm, SOS
- Display in the APP at low battery level
- Transmission frequency/distance 868MHz/~10m open areas
- Weight / Dimensions 20g (with battery) / (L) 6.2 x (W) 3.0 x (H) 1.4cm
Also available as single device. EAN code 4260358122533, Article No. 4692
